Sursa Sharkoon ATX SS Cool Zero 750W

General Form Factor: ATX 2.4 Continuous Power: 750 W ErP Compliant: ✓ Active PFC: ✓ Technology: LLC + DC/DC Japanese Primary Capacitors: ✓ All Japanese Capacitors: ✓ MTBF: Min. 100,000 Hours Operating Temperature: 0 °C - 40 °C Standby Power Consumption: 0.16 W Weight incl. Fixed Cables: 2.6 kg Dimensions (L x W x H): 150 x 160 x 86 mm Housing Color: Black Input Voltage: 100 - 240 VAC Frequency: 50 - 60 Hz Input Current (110/230 V): 10 A Output 12 V Rail(s): 1 Load 3.3 V: 22 A Load 5 V: 22 A Max. Combined Power 3.3 V + 5 V: 120 W Load 12 V1: 62.5 A Max. Combined Power 12 V: 750 W Load 5 VSB: 3 A Load -12 V: 0.3 A Cable and Connectors Cable Configuration: Fully Modular Flat Cables: ✓ Maximum Cable Length: 115 cm Length of Mainboard Cable: 56 cm Length of CPU Cable: 62.5 cm Length of PCIe Cable: 55 cm + 15 cm Cable Length to First Peripheral: 55 cm 24-Pin Mainboard Connector: 1 4+4-Pin CPU Connector: 2 6+2-Pin PCIe Connector: 4 SATA Connector: 12 IDE Connector: 2 Floppy Connector: 1 Fan Fan Size: 135 mm Bearing Type: Fluid Dynamic Bearing Protections OCP (Over-Current Protection): ✓ OVP (Over-Voltage Protection): ✓ UVP (Under-Voltage Protection): ✓ SCP (Short-Circuit Protection): ✓ OTP (Over-Temperature Protection): ✓ OPP (Over-Power Protection): ✓ Safety Certifications CE: ✓ FCC: ✓ CB: ✓

• GENERAL

  Recomandat Gaming



  Da
  Putere sursa



  750 W
  Numar de ventilatoare



  1x 135 mm
  Voltaj/Amperaj



  100 - 240V, 10A, 50/60Hz
  Tip sursa



  ATX 2.4
  Sursa Modulara



  Da, Full Modulara
  PFC



  Active
  Certificare



  80+ Gold
  Eficienta



  87 %
  Protectii



  OVP, OCP, OPP, SCP, UVP, OTP
  Iluminare LED



  Nu
  Dimensiuni



  150 x 160 x 86 mm
  Greutate



  2.6 kg
  Permite Asamblare



  Standard
  Permite Wire Management



  Da

• CONECTORI

  24 Pin ATX



  1
  4+4 Pin ATX/EPS



  2
  6+2 PCI-E



  4
  SATA



  12
  Molex



  2
  Floppy



  1

• TENSIUNI

  +5Vsb



  3 A
  -12V



  0.3 A
  +12V 1



  62.5 A
  +5V



  22 A
  +3.3V



  22 A
  Rail +12V



  1
